Reactis for Simulink

Reactis for Simulink reads and processes SLX files created in the Simulink enviroment of The MathWorks. Reactis consists of three main components: Reactis Tester, Reactis Simulator, and Reactis Validator.

Reactis Tester

Generate tests automatically
  • Will unexpected inputs cause a runtime error?
  • How much of my model have I really tested?

Reactis Tester employs a patented technology called guided simulation to build test suites. The tool tracks an array of coverage metrics as it computes test data, and it uses uncovered targets of these metrics to influence the creation of subsequent tests.

generate tests from Simulink/Stateflow model

Coverage metrics include generic objectives such as Decision, Condition, and Modified Condition/Decision Coverage (MC/DC), Simulink-specific measures such as branch and subsystem, and Stateflow-specific metrics such as state, condition-action, and transition-action.

comparing code to a model

Testing code (auto-generated or hand-written) against your model is easy with Reactis:

  1. Generate tests from model
  2. Run tests on code
  3. Differences are automatically detected and flagged.

Reactis Simulator

Simulate and debug

How do I understand, diagnose, and fix a bug?

  • Execute a block, single step, or multiple steps at a time.
  • Reverse execution.
  • To see data values, hover with the mouse, open a scope, or add to watched variables.
  • Unexercised parts of model are highlighted in red.
  • Generate detailed coverage reports.
  • Breakpoints.
  • When using the Reactis for C Plugin or the Reactis for EML Plugin, it's like having an advanced source code debugger right in your Simulink environment. Debugging Simulink, Stateflow, Embedded MATLAB, and C code is all controlled from the same simple interface.
debug Simulink models

Reactis Validator

Check requirements
  • Will the brake always deactivate the cruise control?

Validator uses a test and check approach for verifying models. You first instrument your model with checks that monitor whether behavior is consistent with expectations. Validator then uses the test-generation component of Tester to create and run test data to see if any checks can be violated. These tests can then be used to diagnose the cause of any abnormal behavior detected.

verify Simulink models

Checks are specified by defining a collection of assertions and user-defined targets. Assertions are properties that should always be true if the model is functioning properly. User-defined targets specify behaviors that should be tested in order to verify that requirements hold. During test-generation, Reactis attempts to violate assertions and exercise user-defined targets. Both assertions and user-defined targets may be formulated as either c-like expressions or as a Simulink/Stateflow observer diagram.



Reactis for C

Reactis for C supports the test, simulation, and validation of standalone C programs (not contained in a model). Reactis for C consists of three main components: Reactis Tester, Reactis Simulator, and Reactis Validator.

Reactis Tester

Generate tests automatically
  • Will unexpected inputs cause a runtime error?
  • How much of my model have I really tested?

Reactis Tester employs a patented technology called guided simulation to build test suites. The tool tracks an array of coverage metrics as it computes test data, and it uses uncovered targets of these metrics to influence the creation of subsequent tests. Coverage metrics include Statement, Decision, Condition, Modified Condition/Decision Coverage (MC/DC), Function, and Function Call.

generate tests from C code

As Reactis Tester generates tests, it performs an array of checks to flag runtime errors in your C code. Memory errors are particularly easy to make in C and can be very hard to debug. A memory error occurs whenever a program reads-from or writes-to an invalid address. Memory errors are particularly common in C programs because the C programming language gives the programmer direct access to the program's memory, which can boost performance but also allows software defects to access arbitrary memory locations.

Some errors flagged by Reactis include out-of-bounds array indexes, buffer overruns, dangling heap pointers (accessing a region of heap-allocated memory after the memory has been freed), dangling stack pointers (accessing a pointer to a local variable of a function after the function has returned) and the use of pointers cast from incorrect numeric values. Reactis Tester not only detects these types of errors, it returns a test that can be executed in Reactis Simulator to pinpoint the underlying cause of the error.

Reactis Simulator

Simulate and Debug

How do I understand, diagnose, and fix a bug?

  • Execute a single statement; step into, over, out of functions; execute a full step or multiple steps at a time.
  • Reverse execution.
  • To see data values, hover with the mouse, open a scope, or add to watched variables.
  • Unexercised parts of code are highlighted in red.
  • Generate detailed coverage reports.
  • Breakpoints.
debug Simulink models

Reactis Validator

Check requirements
  • Will the brake always deactivate the cruise control?

Validator uses a test and check approach for verifying C code. You first instrument your code with checks that monitor whether behavior is consistent with expectations. Validator then uses the test-generation component of Tester to create and run test data to see if any checks can be violated. These tests can then be used to diagnose the cause of any abnormal behavior detected.

verify C code

Eliminating runtime errors is important, but only one step towards high-quality software. A program that does not crash, but does the wrong thing is also unacceptable. Reactis Validator gives you a way to formulate and perform checks that your program is operating properly. Checks are formulated in a way similar to the assert mechanism of C.
